SPL-RG-309A
Power
Input voltage：AC100-240V 50/60Hz
Power consumption：60W
Fuse：T2A/250V
Fixture
IP rating：IP20
Cooling method: fan cool
Max ambient temp：45℃
Case color：black
LED
Spot Derby: 8*3W single color LED, R2/G2/B2/Y2
Strobe: 2*3W white LED
UV: 8*3W UV LED
Laser: 1*80mW 650nm red +30mW 532nm green (no laser for SPL-LED-309B)
Average lifespan: 50,000 hours
Control
DMX channel：2/10CH (2/8CH for SPL-LED-309B)
DMX connector：3Pin XLR input/output
Power connector: IEC input
control mode：DMX/master-slave/auto/sound
IR remote control for easy use
Built-in laser pattern: 12pcs
3B laser safety class with key switch and interlock
LED display
8 small gobos (2 gobos for each R,G,B,Y）
3*5 lens for gobo derby
Color effect
Color：R,G,B, Y, W,UV
Dimming：0-100%
Strobe：25/S
Dimension
Product dimension: 230*245*191.5mm
Net weight：2Kg
